SGS - #90, 118° Point, Solid Carbide Micro Drill Bit
Item #: 10234961
Brand: SGS
Model #: 07250
Product Specifications
| Drill Bit Size (Wire) | #90 |
| Drill Bit Size (Decimal Inch) | 0.0087 |
| Shank Diameter (mm) | 3 |
| Shank Diameter (Inch) | 0.125 |
| Drill Point Angle | 118 |
| Drill Bit Material | Solid Carbide |
| Drill Bit Finish/Coating | Uncoated |
| Cutting Direction | Right Hand |
| Overall Length (Decimal Inch) | 1.5 |
| Overall Length (Inch) | 1.5 |
| Flute Length (mm) | 19.00 |
| Flute Length (Decimal Inch) | 0.1 |
| Flute Length (Inch) | 0.1 |
| Flute Type | Spiral |
| Shank Type | Straight |
| Material Grade | Micrograin |
| Series/List | M105 |
| PSC Code | 3455 |
