Sandvik Coromant - 1.25 Connection, 3/8" Cutting Width, 1.083" Depth of Cut, 1-1/4" Hole Diam, 8 Tooth Indexable Slotting Cutter - N331.32..Txx.. MQ Toolholder, RCKT 09 T3 00 Insert, Neutral Cutting Direction
Item #: 49541493
Brand: Sandvik Coromant
Model #: 5738028
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | 1.25 |
| Cutting Width (mm) | 9.53 |
| Cutting Width (Decimal Inch) | 0.3750 |
| Cutting Width (Decimal Inch) | 0.375 |
| Cutting Width (mm) | 9.525 |
| Maximum Depth of Cut (mm) | 27.51 |
| Maximum Depth of Cut (Decimal Inch) | 1.0830 |
| Maximum Depth of Cut (Decimal Inch) | 1.083 |
| Maximum Depth of Cut (mm) | 27.51 |
| Hole Diameter (mm) | 31.75 |
| Hole Diameter (Decimal Inch) | 1.2500 |
| Modular Connection Size | 1.25 |
| Number of Teeth | 8 |
| Toolholder Style | N331.32..Txx.. MQ |
| Series | CoroMill 331 |
| Insert Style | RCKT 09 T3 00 |
| Number of Cutter Inserts | 8 |
| Cutting Direction | Neutral |
| Cutting Direction | Neutral |
| Insert Holding Method | Screw |
| Insert Holding Method | Screw |
| Maximum RPM | 18100 |
| Maximum RPM | 18100 |
| Hub Diameter (mm) | 46.00 |
| Hub Diameter (Decimal Inch) | 1.8110 |
| Hub Diameter (mm) | 46.00 |
| Hub Diameter (Decimal Inch) | 1.8110 |
| Keyway Width (Decimal Inch) | 0.3120 |
| Keyway Width (mm) | 7.92 |
| Keyway Width (Decimal Inch) | 0.3120 |
| Through Coolant | No |
| Complete Insert Compatibility1 | RCKT 09 T3 00 |
