Kyocera - 63mm Cut Diam, 6mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 4 Inserts, PN.U 1205 Insert, Right Hand Cut, 4 Flutes, Series MFPN
Item #: 50421072
Brand: Kyocera
Model #: 8835298
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 0 |
| Cutting Diameter (mm) | 63.00 |
| Cutting Diameter (Decimal Inch) | 2.4803 |
| Arbor Hole Diameter (Inch) | 0 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 4.330709 |
| Overall Height (mm) | 110 |
| Insert Compatibility | PN.U 1205 |
| Series | MFPN |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 6.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362 (GM/SM/GH); 0.1969 (GL); 0.1181 (W) |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | MFPN |
| Number of Flutes | 4 |
| Cutting Rake Angle | -10 |
| Rake | Negative |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | PNEU 1205ANER-GL; PNEU 1205ANER-W; PNMU 1205ANER-GH; PNMU 1205ANER-GM; PNMU 1205ANER-SM |
