Accurate Bushing - 3" Roller Diam x 1-3/4" Width, 1-1/4" Stud Diam x 2-1/2" Length, Sealed Self Lubricating Stud Cam Follower with Nonmetallic Bushing - Carbon Steel, 1-1/4" Thread Length, 1-1/4-12 Thread, 4-1/4" OAL
Item #: 62901905
Brand: Accurate Bushing
Model #: BCR-3-X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Self-Lubricating Stud Cam Follower with Non-Metallic Bushing |
| Roller Diameter (Decimal Inch) | 3.0000 |
| Roller Diameter (Inch) | 3 |
| Roller Width (Decimal Inch) | 1.7500 |
| Stud Diameter (Decimal Inch) | 1.2500 |
| Dynamic Load Capacity (N) | 0 |
| Static Load Capacity | 0 |
| Length (Decimal Inch) | 4.250 |
| Thread Size | 1-1/4-12 |
| Material | Carbon Steel |
| Stud Length (Decimal Inch) | 2.5000 |
| Stud Length (Inch) | 2-1/2 |
| Thread Length (Inch) | 1-1/4 |
