Indexable Turning Toolholders; Cutting Direction: Right Hand; Compatible Insert Size Code: SN..1506.; Toolholder Style: PSSNR; Rake: Negative; Rake Angle: 0; Multi-use Tool: No; Lead Angle: 45.0; Insert Holding Method: Lever; Shank Width (mm): 32.00; Shan
Item #: 73553281
Brand: Ceratizit
Model #: 70512132
Product Specifications
| Cutting Direction | Right Hand |
| Compatible Insert Size Code | SN..1506. |
| Toolholder Style | PSSNR |
| Rake | Negative |
| Rake Angle | 0 |
| Multi-use Tool | No |
| Lead Angle | 45.0 |
| Insert Holding Method | Lever |
| Shank Width (mm) | 32.00 |
| Shank Height (mm) | 32.00 |
| Series | MAXILOCK N |
| Overall Length (mm) | 181.20 |
| Overall Length (Decimal Inch) | 181.2000 |
| Cutting Tool Application | Turning |
| Head Length (mm) | 38.90 |
| Back of Bar to Cutting Edge (mm) | 40.00 |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Insert Thickness | 6.35 |
| Insert Inscribed Circle (mm) | 15.87 |
