CNMX554HB TT8135
Item #: IC065523668
Brand: Ingersoll
Model #: 5523668
| Product Specifications | |
|---|---|
| Insert Style | CNMX |
| Grade | TT8135 |
| Corner Radius (RE) | 0.063″ |
| Min D.O.C. | 0.06″ |
| Insert Size | 554 |
| Depth of Cut Maximum (APMX) | 0.315″ |
| Cutting Edge Length (L) | 0.567″ |
| Min. Turning Feed (ft(min)) | 0.012″ |
| Insert Thickness (S) | 0.272″ |
| Max. Turning Feed (ft(max)) | 0.031″ |
| Inscribed Circle Diameter (IC) | 5/8″ |
| Measurement Type | Inch |
| Coating | TiCN+Al2O3+TiN |
| Body Material | Carbide |
