1/4″ × 1/4″ × 3/8″ × 4″ 4 Flute Square End Carbide End Mill-Plain Shank - Y-Coating
Item #: YG35UGMH10016
Brand: YG-1 Cutting Tools
Model #: UGMH10016
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 1/4″ |
| Shank Type | Plain |
| Connection Diameter Machine Side (DCONMS) | 1/4″ |
| End Shape | Square |
| Depth of Cut Maximum (APMX) | 3/4″ |
| Usable Length (LU) | 3/8″ |
| Overall Length (OAL) | 4″ |
| Applicable Material | Stainless Steel | Cast Iron | Super-Alloys / Titanium |
| Cutting Edge Material | Carbide |
| Tool Type | 4 Flute Extended Length |
| Coating | Y-Coating |
| Decimal Equivalent | 0.25″ |
| Flute Count (NOF) | 4 |
| Measurement Type | Inch |
| Flute Helix Angle (FHA) | 36 Degrees |
| Series/List # | UGMH10 |
