Renishaw - 1/2 Inch Ball Diameter, Stainless Steel Stem, M3 Thread, Steel Point Disc Tip CMM Stylus - 2.2 mm Working Length, 0.1378 Inch Stem Diameter, 30.8 mm Overall Length
Item #: 00551747
Brand: Renishaw
Model #: A-5000-3615
Exact Tooling IR#: 04
Features and Benefits
The stylus is the spherical portion or tip of the probe that makes contact with the workpiece surface. It is commonly made of a synthetic ruby and mounted on a stem.
Disc type stylus' are used for probing undercuts and grooves. They are commony used for probing X and Y axis.
| Product Specifications | |
|---|---|
| Stylus or Probe | Stylus |
| Stylus Type | Disc |
| Stylus Thread Size | M3 |
| Point Material | Steel |
| Ball Diameter (mm) | 12.70 |
| Ball Diameter (Decimal Inch) | 0.5000 |
| Overall Length (mm) | 30.80 |
| Stem Material | Stainless Steel |
| Stem Diameter (mm) | 3.50 |
| Stem Diameter (Decimal Inch) | 0.1378 |
| Effective Working Length (mm) | 2.20 |
