Wilkerson - Coalescing Filters Port Size: 1/4 Maximum Working Pressure (psi): 150
Item #: 11758554
Brand: Wilkerson
Model #: M18-02-CG00B
Product Specifications
Coalescing Filters; Port Size: 1/4 ; Maximum Working Pressure (psi): 150 ; Bowl Material: Polycarbonate ; Width (Decimal Inch): 2.3600 ; Height (Inch): 8-3/8 ; Height (Decimal Inch): 8.360
| Port Size | 1/4 |
| Maximum Working Pressure (psi) | 150 |
| Bowl Material | Polycarbonate |
| Width (Decimal Inch) | 2.3600 |
| Height (Inch) | 8-3/8 |
| Height (Decimal Inch) | 8.360 |
| Micron Rating | 5µ |
| Drain Type | Auto |
| Cubic Feet per Minute | 36 |
| Maximum Temperature (F) | 125 |
| Bowl Capacity | 1.7 oz |
| Bowl Guard Material | Plastic |
| Sight Glass | Yes |
| Series | 18 |
| Pressure Gauge Included | No |
| Bowl Guard | Yes |
| Type | Coalescing Filter |
