US Motors - 1/2 hp, ODP Enclosure, Manual Thermal Protection, 1,625 RPM, 115 Volt, 60 Hz, Single Phase Permanent Split Capacitor (PSC) Motor - Size 56 Frame, Rigid Mount, 1 Speed, Ball Bearings, 5.00 Full Load Amps, B Class Insulation, Reversible
Item #: 04091443
Brand: US Motors
Model #: D12ARM2N
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Motor Type | Single Phase Permanent Split Capacitor (PSC) |
| Type of Enclosure | ODP |
| Horsepower | 1/2 |
| Thermal Protection Rating | Manual |
| Name Plate RPMs | 1625 |
| Voltage | 115 |
| Frequency Hz | 60 |
| Frame Size | 56 |
| Mount Type | Rigid |
| Number of Speeds | 1 |
| Bearing Type | Ball |
| Full Load Amperage | 5.00 |
| Insulation Class | B |
| Overall Length (Decimal Inch) | 10.3700 |
| Shaft Diameter x Length (Inch) | 5/8 x 1-7/8 |
| Full Load Efficiency Rating | 63.00 |
| Service Factor Rating | 1.00 |
| Motor Rotation | Reversible |
| PSC Code | 6105 |
