Indexable Turning Toolholder: SVJCL123, 93.000 deg Lead Angle, Screw
Item #: 62160759
Brand: Tungaloy
Model #: 6864099
Product Specifications
| Toolholder Style | SVJC |
| Hand of Holder | Left Hand |
| Lead Angle | 93.000 |
| Insert Compatibility | VC..33. |
| Insert Holding Method | Screw |
| Shank Width (Inch) | 3/4 |
| Shank Height (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 4.5000 |
| Rake | Positive |
| Cutting Direction | Left Hand |
| Compatible Insert Size Code | VC..33. |
| Multi-use Tool | Yes |
| Shank Width (Decimal Inch) | 0.7500 |
| Shank Height (Decimal Inch) | 0.7500 |
| Series | SVJC |
| Overall Length (Inch) | 4-1/2 |
| Cutting Tool Application | Facing; Turning |
| Head Length (Decimal Inch) | 1.2500 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.9550 |
| Primary Workpiece Material | Universal |
| Insert Inscribed Circle (Inch) | 3/8 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Insert Thickness (Decimal Inch) | 0.1870 |
| Toolholder Style | SVJC |
| Hand of Holder | Left Hand |
| Lead Angle | 93.000 |
| Insert Compatibility | VC..33. |
| Insert Holding Method | Screw |
| Shank Width (Inch) | 3/4 |
| Shank Height (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 4.5000 |
| Rake | Positive |
| Cutting Direction | Left Hand |
| Compatible Insert Size Code | VC..33. |
| Multi-use Tool | Yes |
| Shank Width (Decimal Inch) | 0.7500 |
| Shank Height (Decimal Inch) | 0.7500 |
| Series | SVJC |
| Overall Length (Inch) | 4-1/2 |
| Cutting Tool Application | Facing; Turning |
| Head Length (Decimal Inch) | 1.2500 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.9550 |
| Primary Workpiece Material | Universal |
| Insert Inscribed Circle (Inch) | 3/8 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Insert Thickness (Decimal Inch) | 0.1870 |
| MSC Part # | 62160759 |
| Mfr Part # | 6864099 |
| Country of Origin Country of Origin is subject to change | Japan |
