Iscar - Arbor Hole Connection, 63/64" Depth of Cut, 100mm Cutter Diam, 0.8661" Hole Diam, 10 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSFU Insert
Item #: 05996731
Brand: Iscar
Model #: 2301102
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Maximum Depth of Cut (mm) | 25.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.9843 |
| Cutter Diameter (mm) | 100.00 |
| Cutter Diameter (Decimal Inch) | 3.9370 |
| Hole Diameter (mm) | 22.00 |
| Hole Diameter (Decimal Inch) | 0.8661 |
| Number of Teeth | 10 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSFU |
| Staggered Tooth | No |
| Number of Cutter Inserts | 10 |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 800 |
| Minimum Cutting Width (Decimal Inch) | 0.0528 |
| Maximum Cutting Width (Decimal Inch) | 0.0528 |
| Maximum Cutting Width (mm) | 1.34 |
| Hub Diameter (mm) | 49.00 |
| Hub Diameter (Decimal Inch) | 1.9291 |
