Pressure Gauge: 2-1/2″ Dial, 0 to 60 psi, 1/4″ Thread, NPT, Center Back Mount Economy Pressure Gauge, Steel Case, Brass Wetted Parts, 3-2-3% of Scale Accuracy
Item #: 07691298
Brand: Winters
Model #: PEM1438
Product Specifications
| Gauge Type | Economy Pressure Gauges |
| Type | Commercial Pressure Gauge |
| Scale Measurement Ranges | 0 to 60 |
| Scale Type | Dual |
| Accuracy (%) | 3-2-3 |
| Dial Type | Analog |
| Thread Type | NPT |
| Type of Liquid Filler | No-Fill |
| Mount Type | Center Back |
| Wetted Parts Material | Brass |
| Dial Diameter (mm) | 63.00 |
| Dial Diameter (Inch) | 2-1/2 |
| Minimum Pressure (psi) | 0.00 |
| Maximum Pressure (Psi - 2 Decimals) | 60 |
| Case Material | Steel |
| Lens Material | Acrylic |
| Thread Size | 1/4 |
| Minimum Scale Measurement | 0 psi |
| Maximum Scale Measurement | 60 psi |
| Standards | NSF-61-372; ANSI/ASME Grade B; IP52; ASME B40.100; CRN |
| Series | PEM |
| Model Number | PEM |
| Display Range | 0 to 60 |
| Minimum Working Temperature (Deg F) | -40 |
| Maximum Working Temperature (F) | 150 |
| Minimum Working Temperature (Deg C) | -40 |
| Maximum Working Temprature (Deg C) | 65 |
