Gates - Belts Belt Style: V-Belts Belt Section: 3L
Item #: 96336565
Brand: Gates
Model #: 92321034
Product Specifications
Belts; Belt Style: V-Belts ; Belt Section: 3L ; Outside Length: 33.000 (Decimal Inch); Outside Length: 838.20 (mm); Belt Width: 0.410 (Decimal Inch); Belt Width: 10.41 (mm)
| Belt Style | V-Belts |
| Belt Section | 3L |
| Outside Length (Decimal Inch) | 33.000 |
| Outside Length (mm) | 838.20 |
| Belt Width (Decimal Inch) | 0.410 |
| Belt Width (mm) | 10.41 |
| Belt Number | 1330 |
| Belt Internal Length (Decimal Inch) | 31.62 |
| Belt Internal Length (mm) | 803.15 |
| Number of Ribs | 0.000 |
| Number of Teeth | 0 |
| Belt Pitch | 0.2 |
| Material | Rubber Compound |
| Belt Height | 0.219 |
| Color | Black |
| Style | Fractional Horsepower |
| Maximum Temperature (F) | 140 |
