Heli-Coil - 1,000 Inserts, 1/4-20 UNC, 1D, Stainless Steel Screw Locking Insert - 3-3/8 Free Coils, 1/4 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, Tangless, 304 Material Grade
Item #: 08469959
Brand: Heli-Coil
Model #: T3585-4C250S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 1/4-20 |
| Overall Insert Length (Decimal Inch) | 0.2500 |
| Tang | Tanged |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1000 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.3100 |
| Maximum Outside Diameter (Decimal Inch) | 0.3300 |
| Number of Free Coils | 3-3/8 |
| Maximum Locking Torque (In/Lb) | 30 |
| Minimum Break Away Torque (In/Lb) | 4.50 |
| Thread Standard | UNC |
| Material Grade | 304 |
