Bison - Adapter Back Plate for 20" Diam Self Centering Lathe Chucks - L-3 Mount, 5.43" Through Hole Diam, 24.82" OD, 4.02" Flange Height, Cast Iron
Item #: 08568834
Brand: Bison
Model #: 7-879-205
Exact Tooling IR#: 04
Features and Benefits
Cast iron offers good vibration, resistance, good wear resistance and machinability. It is heavier and more economical than steel.
| Product Specifications | |
|---|---|
| Nominal Chuck Size | 20 |
| Spindle Nose Type | L Series |
| Mount | L-3 |
| Chuck Compatibility | Self-Centering Chucks |
| Through-Hole Diameter (Decimal Inch) | 5.4300 |
| Chuck Diameter Compatibility (Inch) | 20 |
| Outside Diameter (Decimal Inch) | 24.8200 |
| Flange Height (Decimal Inch) | 4.0200 |
| Material | Cast Iron |
