Kennametal - 4 to 6mm Diam, Hydraulic Chuck, 25.7mm Body Shank Diam, 45° Combo Chamfer and Countersink Drill - 6mm Drill Shank Diam, 3.42805R001 Insert, 49.5mm OAL
Item #: 09201732
Brand: Kennametal
Model #: 1245739
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Hydraulic Chuck |
| Maximum Drill Diameter (mm) | 6.00 |
| Minimum Drill Diameter (mm) | 4.00 |
| Body Shank Diameter (mm) | 25.70 |
| Chuck Shank Diameter (mm) | 25.70 |
| Drill Shank Diameter (mm) | 6.00 |
| Number of Drill Inserts | 2 |
| Insert Style | 3.42805R001 |
| Chamfer Angle | 45 |
| Body Diameter (mm) | 38.00 |
| Overall Length (mm) | 49.50 |
| Included Angle | 90 |
| Insert Holding Method | Clamp; Screw |
| Shank Length (mm) | 21.00 |
| Maximum Screw Adjustment (mm) | 5.00 |
| Through Coolant | NonThrough Coolant |
| Series | SEFAS |
| Includes | Clamp; Screw; Wrench |
