Seco - 137mm Cut Diam, 40mm Arbor Hole, 6mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 8 Inserts, SE.X 1204 Insert, Right Hand Cut, 8 Flutes, Through Coolant, Series R220.53
Item #: 09293192
Brand: Seco
Model #: 07879
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 137.00 |
| Arbor Hole Diameter (mm) | 40.00 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 2.4803 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | SE.X 1204 |
| Series | R220.53 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 6.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362 |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw |
| Cutter Style | R220.53 |
| Number of Flutes | 8 |
| Keyway Width (mm) | 16.40 |
| Cutting Direction | Right Hand |
| Pitch | Normal |
