Camel Grinding Wheels - 7" Diam x 1-1/4" Hole x 3/4" Thick, I Hardness, 100 Grit Surface Grinding Wheel - Silicon Carbide, Type 5, Fine Grade, 3,760 Max RPM, Vitrified Bond, One-Side Recess
Item #: 09493297
Brand: Camel Grinding Wheels
Model #: 34646
Exact Tooling IR#: 04
Features and Benefits
Harder than ceramic, silicon carbide is a fast-cutting abrasive. Commonly used on nonferrous metals and in low-pressure applications.
One Side Recessed.
| Product Specifications | |
|---|---|
| Wheel Diameter (Inch) | 7 |
| Hole Size (Inch) | 1-1/4 |
| Wheel Thickness (Inch) | 3/4 |
| Wheel Hardness | I |
| Abrasive Material | Silicon Carbide |
| Grade | Fine |
| Grit | 100 |
| Wheel Type Number | Type 5 |
| Maximum RPM | 3760 |
| Wheel Color | Green |
| Bond Type | Vitrified |
| Recess Type | One-Side |
| Recess Depth (Inch) | 1/4 |
| Recess Diameter (Inch) | 3 |
| Specification | GC100-I-V |
| Wheel Hardness Rating | Medium |
