Kennametal - Neutral Cut, KM40 Modular Connection, Spring Pack Lathe Modular Clamping Unit - 61.95mm Square Shank Diam, 5.695" OAL, Through Coolant, Series NACA-DS Axial Disc Spring Unit
Item #: 09730276
Brand: Kennametal
Model #: 1021702
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Clamping Unit Type | Spring Pack |
| Series Code | NACA-DS Axial Disc Spring Unit |
| Connection Size | KM40 |
| Cutting Direction | Neutral |
| Shank Diameter (mm) | 61.95 |
| Shank Diameter (Decimal Inch) | 2.4390 |
| Through Coolant | Yes |
| Head Height (mm) | 100.08 |
| Head Height (Decimal Inch) | 3.9400 |
| Overall Length (mm) | 144.65 |
| Overall Length (Decimal Inch) | 5.6950 |
| Head Length (Decimal Inch) | 2.1650 |
| Head Length (mm) | 54.99 |
| Shank Length (mm) | 89.66 |
| Shank Length (Decimal Inch) | 3.5300 |
