Kennametal - Left Hand Cut, KM40 Modular Connection, Adapter/Mount Lathe Modular Clamping Unit - 40.01mm Square Shank Diam, 5.236" OAL, Through Coolant, Series CLAV-VDI Axial
Item #: 09731142
Brand: Kennametal
Model #: 1145075
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Clamping Unit Type | Adapter/Mount |
| Series Code | CLAV-VDI Axial |
| Connection Size | KM40 |
| Cutting Direction | Left Hand |
| Shank Diameter (mm) | 40.01 |
| Shank Diameter (Decimal Inch) | 1.5750 |
| Through Coolant | Yes |
| Head Height (mm) | 83.06 |
| Head Height (Decimal Inch) | 3.2700 |
| Overall Length (mm) | 132.99 |
| Overall Length (Decimal Inch) | 5.2360 |
| Head Length (Decimal Inch) | 2.7560 |
| Head Length (mm) | 70.00 |
| Shank Length (mm) | 62.99 |
| Shank Length (Decimal Inch) | 2.4800 |
