Indexable Grooving Toolholder: SNGL08H06, Uses 6 Inserts, No
Item #: 09993825
Brand: Tungaloy
Model #: 6806537
Product Specifications
| Toolholder Type | Internal Grooving |
| Insert Seat Size | 6 |
| Cutting Direction | Left Hand |
| Maximum Depth of Cut (mm) | 1.50 |
| Minimum Groove Width (mm) | 1.00 |
| Maximum Groove Width (mm) | 2.00 |
| Toolholder Style | SNG |
| Insert Holding Method | Screw |
| Compatible Insert Size Code | 6 |
| Shank Height (mm) | 7.00 |
| Series | SNG |
| Shank Length (mm) | 100.00 |
| Overall Length (mm) | 100.00 |
| Cutting Tool Application | Grooving |
| Center to Cutting Edge (mm) | 4.70 |
| Minimum Hole Diameter (Decimal Inch) | 8.0000 |
| Head Height (Decimal Inch) | 7.0000 |
| Head Height (Inch) | 7 |
| Head Length (mm) | 18.00 |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Coolant Through | No |
