Techniks - Retention Knobs Type: Standard Taper Size: BT50
Item #: 10122331
Brand: Techniks
Model #: 17824
Exact Tooling IR#: 04
Features and Benefits
Retention knobs, also known as pull studs, are threaded components that enable the mounting of a toolholder to the spindle of a CNC milling machine. Retention knobs are held in the machine by a clamp or spring.
Product Specifications
Retention Knobs; Type: Standard ; Taper Size: BT50 ; Thread Size: M24 ; Angle Radius: 45.00 ; Knob Diameter (mm): 23.00 ; Through Coolant: Yes
| Type | Standard |
| Taper Size | BT50 |
| Thread Size | M24 |
| Angle Radius | 45.00 |
| Knob Diameter (mm) | 23.00 |
| Through Coolant | Yes |
| Overall Length (Decimal Inch) | 3.3465 |
