Micro Drill Bit: 0.0091″ Dia, 118 °, Solid Carbide Bright/Uncoated, RH Cut, Spiral Flute, Straight-Cylindrical Shank
Item #: 10223543
Brand: SGS
Model #: 07742
Product Specifications
| Drill Bit Size (mm) | 0.23 |
| Drill Bit Size (Decimal Inch) | 0.0091 |
| Tool Material | Solid Carbide |
| Flute Length (mm) | 3.80 |
| Coating/Finish | Bright/Uncoated |
| Drill Point Angle | 118 |
| Cutting Direction | Right Hand |
| Overall Length (mm) | 38.00 |
| Flute Type | Spiral |
| Shank Type | Straight-Cylindrical |
| Shank Diameter (Decimal Inch) | 0.1181 |
| Shank Diameter (mm) | 3.00 |
| Shank Length (mm) | 3.00 |
| Material Grade | Micrograin |
