SGS - 0.25mm, 118° Point, Solid Carbide Micro Drill Bit
Item #: 10223634
Brand: SGS
Model #: 07744
Product Specifications
| Drill Bit Size (Decimal Inch) | 0.0098 |
| Drill Bit Size (mm) | 0.25 |
| Shank Diameter (mm) | 3 |
| Shank Diameter (Inch) | 0.1181 |
| Drill Point Angle | 118 |
| Drill Bit Material | Solid Carbide |
| Drill Bit Finish/Coating | Uncoated |
| Cutting Direction | Right Hand |
| Overall Length (mm) | 38.00 |
| Flute Length (mm) | 3.80 |
| Flute Length (Decimal Inch) | 0.1496 |
| Flute Length (Inch) | 0.1496 |
| Flute Type | Spiral |
| Shank Length (mm) | 3.000 |
| Shank Type | Straight |
| Material Grade | Micrograin |
| Series/List | M226 |
| PSC Code | 3455 |
