SGS - 1.1mm, 140° Point, Solid Carbide Micro Drill Bit
Item #: 10224970
Brand: SGS
Model #: 06031
Product Specifications
| Drill Bit Size (Decimal Inch) | 0.0394 |
| Drill Bit Size (mm) | 1.1 |
| Shank Diameter (mm) | 4 |
| Shank Diameter (Inch) | 0.1575 |
| Drill Point Angle | 140 |
| Drill Bit Material | Solid Carbide |
| Drill Bit Finish/Coating | TiCN |
| Cutting Direction | Right Hand |
| Flute Length (mm) | 20.30 |
| Flute Length (Decimal Inch) | 0.7992 |
| Flute Length (Inch) | 0.7992 |
| Flute Type | Spiral |
| Shank Type | Straight |
| Material Grade | Micrograin |
| Series/List | M814 |
| PSC Code | 3455 |
