Mahr - Electronic Calipers; Minimum Measurement (mm): 0.00 ; Minimum Measurement (Decimal Inch): 0.0000 ; Maximum Measurement (Decimal Inch): 6 ; Maximum Measurement (mm): 140.00 ; Accuracy Plus/Minus (Decimal Inch): 0.0010 ; Accuracy Plus/Minus (mm): 0.
Item #: 12493086
Brand: Mahr
Model #: 4103377KAL
Product Specifications
Electronic Calipers; Minimum Measurement (mm): 0.00 ; Minimum Measurement (Decimal Inch): 0.0000 ; Maximum Measurement (Decimal Inch): 6 ; Maximum Measurement (mm): 140.00 ; Accuracy Plus/Minus (Decimal Inch): 0.0010 ; Accuracy Plus/Minus (mm): 0.0300
| Minimum Measurement (mm) | 0.00 |
| Minimum Measurement (Decimal Inch) | 0.0000 |
| Maximum Measurement (Decimal Inch) | 6 |
| Maximum Measurement (mm) | 140.00 |
| Accuracy Plus/Minus (Decimal Inch) | 0.0010 |
| Accuracy Plus/Minus (mm) | 0.0300 |
| Resolution (Decimal Inch) | 0.0005 |
| Resolution (mm) | 0.0100 |
| IP Rating | IP67 |
| Data Output | Integrated Wireless |
| Calibrated | Yes |
| Jaw Length (mm) | 40.00 |
| Jaw Style | Angled Jaw |
| Application | For Measuring Wall Thicknesses and Recesses on Shafts; Special Applications |
| Material | Stainless Steel |
| Jaw Material | Stainless Steel |
| Power Source | Battery |
| Battery Type | 3 Volt Lithium CR2032 |
| Additional Information | Model Number: 16 EWRi-SA; Length: 235 mm; Scale Width: 16 mm; Nib Height: 2.5 mm; Height of Digits: 11 mm; Battery life: Approx. 3 yr; Function: ON/OFF, AUTO-ON/OFF, mm/inch, LOCK Function (Key Lock), RESET (Set Display to Zero), PRESET (For Entering a Nu |
| Trade Name | MarCal |
| Nib Size (mm) | 10.00 |
| Includes Depth Measurement Rod | No |
| Includes | Battery; Case; Instruction Manual |
