Indexable Boring Bar: A08H SCMCL 06, 10.50 mm Min Bore, 8.00 mm Shank Dia, 50.00° N/A Steel 104.1500″ OAL, Screw Clamping,
Item #: 12680815
Brand: Ceratizit
Model #: 70723208
Product Specifications
| Minimum Bore Diameter (mm) | 10.50 |
| Maximum Bore Depth (Decimal Inch) | 0.7874 |
| Toolholder Style | SCMCL |
| Tool Material | Steel |
| Shank Diameter (Decimal Inch) | 8.0000 |
| Shank Diameter (mm) | 8.00 |
| Shank Diameter (Inch) | 8 |
| Overall Length (Decimal Inch) | 104.1500 |
| Overall Length (mm) | 104.15 |
| Compatible Insert Size Code | CC..21.5. |
| Insert Holding Method | Screw Clamping |
| Compatible Insert Shape | Diamond |
| Insert Included | No |
| Rake | Positive |
| Cutting Direction | Left Hand |
| Rake Angle | 7.00 |
| Lead Angle | 50.00 |
| Series | MaxiLock-S |
| Insert Inscribed Circle (Inch) | 1/4 |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Compatible Insert Thickness (Decimal Inch) | 0.0938 |
| Multi-use Tool | No |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (mm) | 5.50 |
| Primary Workpiece Material | Universal |
| Coolant Through | Yes |
