Fixed Lifting Eye Bolt: With Shoulder, 4,700 lb Capacity, 3/4 ™ Thread, Grade 316 Stainless Steel Partially Threaded, 12″ Shank, 12″ Thread Length
Item #: 13461959
Brand: US Cargo Control
Model #: SSSEB34X12
Product Specifications
| Eye Bolt Type | Fixed |
| Shoulder Type | With Shoulder |
| Lifting Capacity (Lb.) | 4700.00 |
| Eye Inside Diameter (Decimal Inch) | 1.5625 |
| Eye Inside Diameter (Inch) | 1-9/16 |
| Eye Outside Diameter (Decimal Inch) | 2.8000 |
| Thread Size | 3/4 in |
| Thread Length (Inch) | 12 |
| Full or Partial Threading | Partially Threaded |
| Thread Length (Mm) ( - 3 Decimals) | 12.01 |
| Thread Length (Decimal Inch) | 12.0100 |
| Overall Length (mm) | 15.39 |
| Overall Length (Decimal Inch) | 15.3900 |
| Shank Length (Inch) | 12 |
| Shank Diameter (Inch) | 3/4 |
| Material | 316 Stainless Steel |
