Fixed Lifting Eye Bolt: Without Shoulder, 1,000 lb Capacity, 1/2 ™ Thread, Grade 316 Stainless Steel Fully Threaded, 2″ Shank, 1-1/2″ Thread Length
Item #: 13462429
Brand: US Cargo Control
Model #: NWEBSS12X2
Product Specifications
| Eye Bolt Type | Fixed |
| Shoulder Type | Without Shoulder |
| Lifting Capacity (Lb.) | 1000.00 |
| Eye Inside Diameter (Decimal Inch) | 1.0000 |
| Eye Inside Diameter (Inch) | 1 |
| Eye Outside Diameter (Decimal Inch) | 1.8500 |
| Thread Size | 1/2 in |
| Thread Length (Inch) | 1-1/2 |
| Full or Partial Threading | Fully Threaded |
| Thread Length (Mm) ( - 3 Decimals) | 1.50 |
| Thread Length (Decimal Inch) | 1.5000 |
| Overall Length (mm) | 3.78 |
| Overall Length (Decimal Inch) | 3.7800 |
| Shank Length (Inch) | 2 |
| Shank Diameter (Inch) | 1/2 |
| Material | 316 Stainless Steel |
