Brand: Vectrax / Part #: TRA026-1PH
Item #: 96239223
Brand: Vectrax
Model #: TRA026-1PH
Product Specifications
| Phase | Three |
| Spindle Speed Control | Geared Head |
| Bed Width (Inch) | 7.3000 |
| Bed Width | 7.3 in; 7.3000 in |
| Distance Between Centers (Inch) | 40 |
| Distance Between Centers | 40 in |
| Cross Slide Travel | 5.7 in; 5.7000 in |
| Gap Length (Decimal Inch) | 6.0000 |
| Gap Length | 6.0 in |
| Swing | 13 in |
| Cross Slide Travel (Decimal Inch) | 5.7000 |
| Spindle Bore Diameter | 35.0 mm; 1.3700 in |
| Swing (Inch) | 13 |
| Spindle Bore Diameter (Inch) | 1.3700 |
| Minimum Spindle Speed | 105 |
| Spindle Nose Designation | D1-5 |
| Maximum Spindle Speed | 2000 |
| Overall Height | 62.2 in; 62.2000 in |
| Overall Depth | 41.73 in; 41.7300 in |
| Minimum Metric Pitch (Decimal Inch) | 0.2000 |
| Number of Inch Threads | 47 |
| Minimum Metric Pitch | 0.2 in |
| Spindle Taper Size (Sleeve) | 3MT |
| Spindle Taper Size | 4MT |
| Tailstock Taper Size | 3MT |
| Tailstock Travel (Decimal Inch) | 4.0000 |
| Tailstock Travel | 4.0 in; 100.0 mm |
| Maximum Threads Per Inch | 144 |
| Min. Longitudinal Feed Per Rev. (Decimal Inch) | 0.0008 |
| Max. Longitudinal Feed Per Rev. (Decimal Inch) | 0.0410 |
| Maximum Longitudinal Feed Per Revolution | 0.041 in |
| Minimum Cross Feed Rate Per Revolution | 0.00002 in |
| Min. Cross Feed Rate Per Revolution (Decimal Inch) | 0.000020 |
| Max. Cross Feed Rate Per Revolution (Decimal Inch) | 0.0136 |
| Maximum Cross Feed Rate Per Revolution | 145.0 mm; 0.0136 in |
| Swing Over Cross Slide (Decimal Inch) | 7.5000 |
| Swing Over Cross Slide (Inch) | 7-1/2 |
| Swing Over Gap (Inch) | 20 |
| Swing Over Gap (Decimal Inch) | 20.0000 |
| Swing Over Gap | 20 in; 20.0 in |
