Laydown Threading Inserts; Insert Style: 22EL; Insert Size Code: 22; Insert Material: Solid Carbide; Manufacturer Grade: IC250; Threads Per Inch: 6; Thread Type: External; Thread Standard: Round; Insert Hand: Right Hand; Included Angle: 60; Chipbreaker: Z
Item #: 16179657
Brand: Iscar
Model #: 5901747
Product Specifications
| Insert Style | 22EL |
| Insert Size Code | 22 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | IC250 |
| Thread Type | External |
| Thread Standard | Round |
| Insert Hand | Right Hand |
| Included Angle | 60 |
| Chipbreaker | Z |
| Series | EL |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Corner Radius (Decimal Inch) | 0.0398 |
| Teeth Per Inch | 6.00 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1900 |
| Coating/Finish | Coated |
