Indexable Turning Toolholders; Hand of Holder: Right Hand; Toolholder Style: SSTH; Rake: Positive; Rake Angle: 0; Multi-use Tool: Yes; Lead Angle: 93.0; Insert Holding Method: Screw; Shank Width (Decimal Inch): 0.6299; Insert Compatibility: DCMW325 ™; DCG
Item #: 18289793
Brand: Kyocera
Model #: THC05132
Product Specifications
| Hand of Holder | Right Hand |
| Toolholder Style | SSTH |
| Rake | Positive |
| Rake Angle | 0 |
| Multi-use Tool | Yes |
| Lead Angle | 93.0 |
| Insert Holding Method | Screw |
| Shank Width (Decimal Inch) | 0.6299 |
| Insert Compatibility | DCMW325?; DCGW325?; DCMT325?; DCET325?; DCMX325?; DCGT325? |
| Shank Height (mm) | 12.00 |
| Series | SSTH |
| Overall Length (mm) | 120.00 |
| Overall Length (Inch) | 4-3/4 |
| Cutting Tool Application | External Turning; Copying; Machining |
| Toolholder Material | Steel |
| ISO Number | SDJCR1216JX11F05 |
| Complete Insert Compatibility | DCMW325?; DCGW325?; DCMT325?; DCET325?; DCMX325?; DCGT325? |
| Coolant Through | No |
