Indexable Grooving Toolholder: STWL2525M15, External Left Hand, No
Item #: 18290742
Brand: Kyocera
Model #: THC04141
Product Specifications
| Internal or External | External |
| Toolholder Type | Face Grooving |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (mm) | 3.00 |
| Minimum Groove Width (mm) | 0.50 |
| Maximum Groove Width (mm) | 2.00 |
| Toolholder Style | STW |
| Insert Holding Method | Screw |
| Insert Compatibility | TWFGL? |
| Shank Width/Diameter (mm) | 25.00 |
| Shank Height (mm) | 25.00 |
| Series | STW |
| Overall Length (mm) | 150.00 |
| Multi-use Tool | No |
| Cutting Tool Application | Micro Face Grooving |
| Vibration Dampening | No |
| Manufacturers Catalog Number | STWL2525M15 |
| Toolholder Material | Steel |
| Coolant Through | No |
