Boring Bar: 2 mm Min Bore, 7 mm Max Depth, Right Hand Cut, Carbide 1.70 mm Shank Dia, 27.30 mm OAL, 0.05 mm Corner Radius
Item #: 18292599
Brand: Kyocera
Model #: TLM40281
Product Specifications
| Boring Bar Type | Boring |
| Cutting Direction | Right Hand |
| Minimum Bore Diameter (mm) | 2.00 |
| Material | Carbide |
| Maximum Bore Depth (mm) | 7.00 |
| Shank Diameter (mm) | 1.70 |
| Overall Length (mm) | 27.30 |
| Finish Coating | Megacoat Nano Plus |
| Corner Radius (mm) | 0.05 |
| Bar End Angle | 30 |
| Manufacturer Grade | PR1725 |
| Series | EZB |
| Coating Process | PVD |
| Manufacturers Catalog Number | EZBR020017ST005FPR1725 |
| Primary Workpiece Material | P |
| Secondary Workpiece Material | M |
