Shuster - NAF207-23, 1-7/16" ID, 4-5/8" OAL x 4-5/8" OAH, 4-Bolt Flange Bearing
Item #: 18647495
Brand: Shuster
Model #: 06156513
Product Specifications
| Type | 4-Bolt Flange Bearing |
| Inside Diameter (Decimal Inch) | 1.4375 |
| Inside Diameter (Inch) | 1-7/16 |
| Width (Decimal Inch) | 2.0150 |
| Width (mm) | 51.10 |
| Overall Length (Inch) | 4-5/8 |
| Overall Length (mm) | 117.0000 |
| Overall Height (Inch) | 4-5/8 |
| Overall Height (Decimal Inch) | 4.6250 |
| Overall Height (mm) | 117.00000 |
| Distance Between Mounting Hole Centers | 92.0000 |
| Distance Between Mounting Hole Centers | 3.625 |
| Material | Cast Iron Housing with Steel Bearing |
| Distance Between Base And Center | 19.0000 |
| Distance Between Base And Center | 0.7500 |
| Lock Type | Eccentric |
