Scientific Cutting Tools - 2-1/2 - 12" Port, 3.52" Spotface Diam, 2" Tube Outside Diam, Plain Pilot, Carbide Tipped Porting Tool
Item #: 44039725
Brand: Scientific Cutting Tools
Model #: AND10050-32SA
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | AND 10050 |
| Pilot Type | Plain |
| Port Thread Size (Decimal Inch) | 2.5000-12 |
| Port Thread Size (Inch) | 2-1/2 - 12 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 32.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 2.000 |
| Tube Outside Diameter Compatibility (Inch) | 2 |
| Minimum Pilot Diameter (Decimal Inch) | 2.4120 |
| Maximum Pilot Diameter (Decimal Inch) | 2.5265 |
| Spotface Diameter (Decimal Inch) | 3.5200 |
| Pilot Length (Decimal Inch) | 0.6670 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 2.1000 |
| Overall Length (Decimal Inch) | 4.6000 |
| Shank Diameter (Decimal Inch) | 1.2500 |
| Shank Length (Decimal Inch) | 2.5000 |
| Seal Angle | 30 |
| Thread Type | UN |
| Flute Type | Straight |
| Number of Flutes | 4 |
