Indexable Ball Nose End Mills; Milling Diameter: 12.00 mm; Maximum Depth Of Cut: 1.50 mm; Maximum Ramping Angle: 0.0; Shank Diameter: 16.00 mm; Shank Type: Weldon Flat; Compatible Insert Style: RDEX; RDHX; Compatible Insert Size Code: RD.X 07T1..; Toolhol
Item #: 19824945
Brand: Ceratizit
Model #: 56443121
Product Specifications
| Milling Diameter | 12.00 mm |
| Maximum Depth Of Cut | 1.50 mm |
| Maximum Ramping Angle | 0.0 |
| Shank Diameter | 16.00 mm |
| Shank Type | Weldon Flat |
| Compatible Insert Style | RDEX; RDHX |
| Compatible Insert Size Code | RD.X 07T1.. |
| Toolholder Style | Carbide Shank |
| Series | R 1002 C |
| Overall Length (mm) | 89.00 |
| Overall Length (Decimal Inch) | 89.00 |
| Overall Length (Inch) | 89.00 |
| Tool Application | Profile Milling; Semi-Finishing; Roughing |
| Insert Holding Method | Screw |
| Toolholder Material | Carbide |
| Through Coolant | None |
| Tapered Neck | No |
| Number of Flutes | 2 |
