Indexable Ball Nose End Mills; Milling Diameter: 35.00 mm; Maximum Depth Of Cut: 3.00 mm; Maximum Ramping Angle: 0.0; Shank Diameter: 35.00 mm; Shank Type: Modular; Compatible Insert Style: RDEX; RDHX; RDMX; RDPX; Compatible Insert Size Code: RD.X 12T3..;
Item #: 19825280
Brand: Ceratizit
Model #: 56403354
Product Specifications
| Milling Diameter | 35.00 mm |
| Maximum Depth Of Cut | 3.00 mm |
| Maximum Ramping Angle | 0.0 |
| Shank Diameter | 35.00 mm |
| Shank Type | Modular |
| Compatible Insert Style | RDEX; RDHX; RDMX; RDPX |
| Compatible Insert Size Code | RD.X 12T3.. |
| Toolholder Style | Carbide Shank |
| Series | R 1000 G |
| Overall Length (mm) | 43.00 |
| Overall Length (Decimal Inch) | 43.00 |
| Overall Length (Inch) | 43.00 |
| Tool Application | Profile Milling; Semi-Finishing; Roughing |
| Insert Holding Method | Screw |
| Toolholder Material | Carbide |
| Through Coolant | Normal Pressure |
| Tapered Neck | No |
| Number of Flutes | 4 |
