Gates - Belts Belt Style: Synchronous Belt Section: Round
Item #: 96341425
Brand: Gates
Model #: 89132600
Product Specifications
Belts; Belt Style: Synchronous ; Belt Section: Round ; Outside Length: 32.830 (Decimal Inch); Outside Length: 833.88 (mm); Belt Width: 1.000 (Decimal Inch); Belt Width: 25.40 (mm)
| Belt Style | Synchronous |
| Belt Section | Round |
| Outside Length (Decimal Inch) | 32.830 |
| Outside Length (mm) | 833.88 |
| Belt Width (Decimal Inch) | 1.000 |
| Belt Width (mm) | 25.40 |
| Belt Number | TP330H100 |
| Belt Internal Length (Decimal Inch) | 33.00 |
| Belt Internal Length (mm) | 838.20 |
| Number of Ribs | 0.000 |
| Number of Teeth | 66 |
| Belt Pitch | 12.7 mm |
| Material | Neoprene |
| Belt Height | 0.082 |
| Color | Black |
| Style | Synchronous |
| Maximum Temperature (F) | 180 |
