Gates - Belts Belt Style: V-Belts Belt Section: 4L
Item #: 96335468
Brand: Gates
Model #: 92572202
Product Specifications
Belts; Belt Style: V-Belts ; Belt Section: 4L ; Outside Length: 23.050 (Decimal Inch); Outside Length: 585.47 (mm); Belt Width: 0.516 (Decimal Inch); Belt Width: 13.11 (mm)
| Belt Style | V-Belts |
| Belt Section | 4L |
| Outside Length (Decimal Inch) | 23.050 |
| Outside Length (mm) | 585.47 |
| Belt Width (Decimal Inch) | 0.516 |
| Belt Width (mm) | 13.11 |
| Belt Number | 6823 |
| Belt Internal Length (Decimal Inch) | 21.28 |
| Belt Internal Length (mm) | 540.51 |
| Number of Ribs | 0.000 |
| Number of Teeth | 0 |
| Belt Pitch | 0.2 |
| Material | Neoprene |
| Belt Height | 0.281 |
| Color | Black |
| Style | Fractional Horsepower |
| Maximum Temperature (F) | 180 |
