Turning Insert: SNMG250924-RP5 WPP20G, Solid Carbide TiCN+Al2O3+TiN Finish, Neutral, 1″ Inscribed Circle, 0.0940″ Corner Radius, 90.00 ° N/A Square, Series SNMG-RP5
Item #: 23205537
Brand: Walter
Model #: 8116145
Product Specifications
| Insert Style | SNMG |
| Insert Shape Code | S |
| Insert Size Code | 866 |
| Insert Shape | Square |
| Clearance Code | N |
| Tolerance Code | M |
| Insert Material | Solid Carbide |
| Manufacturer Grade | WPP20G |
| Hole Diameter (Decimal Inch) | 0.3590 |
| Maximum Depth of Cut (Decimal Inch) | 1.0000 |
| Inscribed Circle (Inch) | 1 |
| Inscribed Circle (Decimal Inch) | 1.0000 |
| Insert Holding Method | Clamp |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 3/8 |
| Corner Radius (Decimal Inch) | 0.0940 |
| Included Angle | 90.00 |
| Relief Angle | 0.000 |
| Series | SNMG-RP5 |
| Coating Process | CVD |
| Insert Length (Inch) | 1 |
| Ansi Code | SNMG866-RP5 WPP20G |
| Iso Code | SNMG250924-RP5 WPP20G |
| Cutting Direction | Neutral |
| Chip Breaker | RP5 |
| Coating/Finish | TiCN+Al2O3+TiN |
