National Twist Drill - 11/64" 130° Cobalt Jobber Drill - Exact Tooling

National Twist Drill - 11/64" 130° Cobalt Jobber Drill


Item #: 58814294
Brand: National Twist Drill
Model #: 027622AW

Features and Benefits

Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (Inch) 11/64
Drill Bit Size (Decimal Inch) 0.1719
Drill Point Angle 130
Drill Bit Material Cobalt
Drill Bit Finish/Coating TiN
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 2-1/8
Flute Length (Decimal Inch) 2.1250
Overall Length (Decimal Inch) 3.2500
Overall Length (Inch) 3-1/4
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0007
Number of Flutes 2
Web Thinning Web-Thinned
$ 3.49
