Walter - 1.0236" Blade Height, 4.3307" OAL, Right Hand Cut, Single End Indexable Cut-Off Blade - 16mm Max Depth of Cut, G1041 C Blade

Walter - 1.0236" Blade Height, 4.3307" OAL, Right Hand Cut, Single End Indexable Cut-Off Blade - 16mm Max Depth of Cut, G1041 C Blade


Item #: ETT-223-808
Mfg Name: WALTER
Mfg Part #: 5915348

Product Information:

Single or Double End: Single / Cutting Direction: Right Hand / Blade Height (mm): 26.00 / Blade Height (Decimal Inch): 1.0236 / Blade Overall Length (mm): 110.00 / Blade Overall Length (Decimal Inch): 4.3307 / Blade Style: G1041 C / Insert Style: GX16-2E3/F3.. / Insert Width (mm): 3.00 / Insert Width (Decimal Inch): 0.1181 / Tool Block/Toolholder Style: SBN / Insert Holding Method: Screw / Maximum Depth of Cut (mm): 16.00 / Maximum Depth of Cut (Decimal Inch): 0.6299 / Cutting Height (mm): 21.00 / Cutting Height (Decimal Inch): 0.8268 / Insert Corner Radius (Decimal Inch): 0.0118 / Complete Insert Compatibility: GX16-2E300N02-CE4; GX16-2E300N02-CF5; GX16-2E300N02-CF6; GX16-2E300N030-GD3; GX16-2E300N030-UA4; GX16-2E300N030-UF4; GX16-2E300N03-GD3; GX16-2E300N03-GD6; GX16-2E300N03-UD6; GX16-2E300N03-UF4; GX16-2E300R/L6-CE4; GX16-2E300R/L6-CF5; GX16-2E300R/L6-CF6 / Complete Tool Block/Toolholder Style Compatibility: SBN12-26K-E; SBN12-26KS-E; SBN16-32-K-E; SBN16-32KS-E; SBN2020-26-K; SBN20-32K-E; SBN20-32KS-E; SBN20-46K-E; SBN2520-32-K; SBN3229-32-K; SBN3229-46-K; SBN4037-46-K / Includes: Clamping Screw FS2164; Screwdriver FS1485

$ 198.00
