DNGU080304MFP-SK Carbide Turning Insert Megacoat Finish, Neutral, 7mm Inscribed Circle, 0.4mm Corner Radius, 3.18mm Thick, 55° Diamond
Item #: 28467462
Brand: Kyocera
Model #: TKE03692
Product Specifications
| Insert Style | DNGU |
| Insert Shape Code | D |
| Insert Size Code | 2221 |
| Insert Shape | Diamond |
| Clearance Code | N |
| Tolerance Code | G |
| Manufacturer Grade | PR1225 |
| Hole Diameter (Mm) ( - 0 Decimals) | 3.60 |
| Hole Diameter (Decimal Inch) | 0.1417 |
| Inscribed Circle (mm) | 7.00 |
| Inscribed Circle (Decimal Inch) | 0.2756 |
| Insert Holding Method | Screw; Clamp |
| Insert Hand | Neutral |
| Insert Thickness | 3.18 |
| Insert Thickness (Decimal Inch) | 0.1252 |
| Corner Radius (mm) | 0.40 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Included Angle | 55.0 |
| Relief Angle | 0 |
| Coating Process | PVD |
| Rake | Negative |
| Primary Workpiece Material | M |
| Secondary Workpiece Material | P |
| Manufacturers Catalog Number | DNGU2221MFPSKPR1225 |
| Chip Breaker | U |
| Multi-Use Tool | Yes |
| Coating/Finish | Megacoat |
| Multi-Use Application | External Turning; Copying |
