Turning Insert: TPMT731PSS T6130, Solid Carbide TiCN & TiN Finish, Neutral, 0.0160″ Corner Radius, 60.0 ° N/A Triangle, Series TPMT
Item #: 28581411
Brand: Tungaloy
Model #: 6994556
Product Specifications
| Insert Style | TPMT |
| Insert Size Code | 731 |
| Insert Shape | Triangle |
| Insert Material | Solid Carbide |
| Manufacturer Grade | T6130 |
| Hole Diameter (Decimal Inch) | 0.0980 |
| Maximum Depth of Cut (Decimal Inch) | 0.0787 |
| Inscribed Circle (Decimal Inch) | 0.2190 |
| Insert Holding Method | Screw |
| Insert Hand | Neutral |
| Insert Thickness (Decimal Inch) | 0.0940 |
| Corner Radius (Decimal Inch) | 0.0160 |
| Included Angle | 60.0 |
| Relief Angle | 11 |
| Series | TPMT |
| Coating Process | CVD |
| Rake | Positive |
| Wiper Edge | No |
| Number Of Cutting Edges | 3 |
| Primary Workpiece Material | Stainless Steel |
| Primary Workpiece Material Code | M |
| Ansi Code | TPMT731PSST6130 |
| Iso Code | TPMT731-PSS T6130 |
| Chip Breaker | PSS |
| Coating/Finish | TiCN; TiN |
