Ball End Mill Heads; Mill Diameter (Inch): 1; Mill Diameter (Decimal Inch): 1.0000; Number of Flutes: 4; Length of Cut (Inch): 0.8600 in; Connection Type: S15; Overall Length (Inch): 1.4500 in; Material: Solid Carbide; Finish/Coating: TiAlN; Cutting Direc
Item #: 29153509
Brand: Tungaloy
Model #: 6717398
Product Specifications
| Mill Diameter (Inch) | 1 |
| Mill Diameter (Decimal Inch) | 1.0000 |
| Number of Flutes | 4 |
| Length of Cut (Inch) | 0.8600 in |
| Connection Type | S15 |
| Overall Length (Inch) | 1.4500 in |
| Material | Solid Carbide |
| Finish/Coating | TiAlN |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Flute Type | Helical |
| Helix Angle | 30 |
| Helix Style | Medium |
| Material Grade | AH725 |
| Maximum Helix Angle | 30 |
| Minimum Helix Angle | 30 |
| Nose Radius (Decimal Inch) | 0.5000 |
| Series/List | VBD |
| Undercutting | No |
