Indexable Grooving Toolholder: QSER16-3T33, 0.1181″ Max Groove Width 1.2990″ Max Depth, Uses 3 Inserts, 1.0000″ Shank Height, 1″ Shank Width, No
Item #: 29161882
Brand: Tungaloy
Model #: 6841456
Product Specifications
| Toolholder Type | External Grooving |
| Insert Seat Size | 3 |
| Cutting Direction | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 1.2990 |
| Minimum Groove Width (Decimal Inch) | 0.1181 |
| Toolholder Style | QSE |
| Maximum Groove Width (Decimal Inch) | 0.1181 |
| Insert Holding Method | Self Grip |
| Compatible Insert Size Code | 3 |
| Shank Width/Diameter (Decimal Inch) | 1.0000 |
| Shank Width/Diameter (Inch) | 1 |
| Shank Height (Inch) | 1 |
| Shank Height (Decimal Inch) | 1.0000 |
| Series | QSE |
| Shank Length (Decimal Inch) | 4.3460 |
| Overall Length (Inch) | 6 |
| Overall Length (Decimal Inch) | 6.0000 |
| Multi-use Tool | Yes |
| Cutting Tool Application | Grooving; Cut-Off |
| Head Length (Decimal Inch) | 1.6540 |
| Toolholder Material | Steel |
| Coolant Through | No |
