Item #: 29448297
Brand: Seco
Model #: 02505797
Product Specifications
| Insert Style | ABER |
| Insert Size Code | 2606 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | T350M |
| Inscribed Circle (Decimal Inch) | 0.5510 |
| Corner Radius (Decimal Inch) | 0.0630 |
| Insert Hand | Right Hand |
| Relief Angle | 5.00 |
| Series | R217/220.99 |
| Coating Process | CVD |
| Hole Diameter (Decimal Inch) | 0.2200 |
| Maximum Depth of Cut (Decimal Inch) | 0.9610 |
| Number Of Cutting Edges | 1 |
| Cutting Edge Effective Length (Decimal Inch) | 0.9610 |
| Insert Shape | Rectangle |
| Rake | Positive |
| Primary Workpiece Material | Stainless Steel |
| Primary Workpiece Material Code | M |
| Secondary Workpiece Material | Cast Iron; Steel |
| Secondary Workpiece Material Code | P; K |
| Ansi Code | ABER2606ZZFR-M15 |
| Iso Code | ABER2606ZZFR-M15 |
| Chip Breaker | M15 |
| Coating/Finish | Coated |
| Included Angle Degree | 85 |
| Thickness (Decimal Inch - 4 Decimals) | 0.2500 |
