Iscar - Shell Mount B Connection, 0.0472" Cutting Width, 80mm Cutter Diam, 1-1/16" Hole Diam, 11 Tooth Indexable Slotting Cutter - TRIB-SM Toolholder, TRI Insert
Item #: 30705222
Brand: Iscar
Model #: 2301953
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount B |
| Cutting Width (mm) | 1.20 |
| Cutting Width (Decimal Inch) | 0.0472 |
| Maximum Depth of Cut (mm) | 0.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.0000 |
| Cutter Diameter (mm) | 80.00 |
| Cutter Diameter (Decimal Inch) | 3.1496 |
| Hole Diameter (mm) | 27.00 |
| Hole Diameter (Decimal Inch) | 1.0630 |
| Number of Teeth | 11 |
| Toolholder Style | TRIB-SM |
| Series | ChamSlit(TRIB-SM) |
| Insert Style | TRI |
| Staggered Tooth | No |
| Number of Cutter Inserts | 11 |
| Insert Holding Method | Screw |
| Maximum Cutting Width (Decimal Inch) | 0.1575 |
| Maximum Cutting Width (mm) | 4.00 |
| Hub Diameter (mm) | 69.70 |
| Hub Diameter (Decimal Inch) | 2.7441 |
| Radius | No |
| Complete Insert Compatibility1 | TRI 16RK-1.2-0.05; TRI 16RK-1.4-O.1; TRI 16RK-1.5-0.1; TRI 16RK-1.7-O.1; TRI 16RK-1.95-0.15 |
